DUST COMMANDER DLX ESD MKII: cyclone filter for individuals, workshops and industry.

NEW MKII version

Improvements compared to the previous version (concerns units delivered after 03/22/2021) :

• - modification of the cyclonic entry profile (reduction of turbulence)

• - the internal diameter of the inlets / outlets is now at the nominal diameter of 50mm

• - the plastic used for the manufacture of the cyclone is now 30% glass-filled polyamid for greater strength

• - increased antistatic properties of the cyclone: ​​surface resistance <1E6 ohm / square

• - the 2 x 50mm adapters have been replaced by 2 x 40 mm adapters

     The paper filter of a vacuum cleaner clogs quickly, reducing suction power at the inlet, which requires frequent cleaning/replacement of the filter. Replacing paper filters is costly and time consuming.

     The DUST COMMANDER DLX ESD MKII, a cyclone-type filter made of injected plastic, is a complement to your workshop vacuum cleaner that will enable you to eliminate the defects of conventional filters. It allows the separation of wet and dry dust particles, thereby limiting the clogging of your vacuum cleaner filters and increasing their service life.

The cyclone separator collects the extracted particles in a sealed chamber that you attach to the base of the cyclone separator.

     The cyclone separator filters 98% of the air its sucks up containing dust and fine particles, only depositing 1% of these on your vacuum cleaner filter, which considerably increases its operating life, power and efficiency.

The cyclone separator can be used for a variety of applications, including:

• - sawing/sanding/wood machining
• - interior renovation, DIY
• - dust extraction from building sites (concrete, plaster, etc.)
• - centralised vacuum cleaning
• - etc...

PLEASE NOTE :

this filter is only suitable for household or workshop vacuum cleaners (e.g. Karcher, Aquavac, Festool, Mafell, Fein, etc.) This filter is NOT compatible with chip collectors (HVLP) equipped with 100 mm inlets/outlets.

Special features of the DLX model:

• - anti-static construction
• - streamlined air inlet
• - parabolic cone
• - transversal particle/chip ejection port

Dimensions :

• - External diameter of the inlet/outlet ducts: 55 mm.
• - Inner diameter of the inlet/outlet ducts: 50 mm
• - Total height: 315 mm.
• - Cyclone diameter: 150 x 60 mm.
• - Construction: black electroconductive PA30GF (glass filled polyamide)

Package contents :

1 x DUST COMMANDER FILTER
1 x ASSEMBLY KIT
2 x 32mm ADAPTERS in ESD polypropylene
2 x 35mm ADAPTERS in ESD polypropylene
2 x 40mm ADAPTERS in ESD polypropylene

The DUST COMMANDER DLX MKII Mounting Kit includes :

4 x DIN 7981 4,2 x 25 stainless steel A2 pan head tapping screw type C, cross recessed H (phillips)
4 x DIN 9021 M5 (5.3) stainless steel A2 washers
1 x rubber gasket
1 x self ashesive cutting template

3D model (in STEP format)

DUST COMMANDER DLX - datasheet

		How does it work? A mixture of air and dust passes through the filter via the tangential inlet. The shape of the filter is designed to generate a vortex which enables the evacuation by gravity of heavier-than-air particles through the lower ejection port and allows air to pass through the upper outlet.
Convenient Vacuum large amounts of dust/chips/rubble/etc. without filling your vacuum bag.	Powerful Never lose suction power thanks to the cyclone effect.	Economical Save time and money by replacing your vacuum bags up to 20 times less often!

[description_short] =>

• - ESD cyclone filter made of 30% glass filled polyamid
• - Inside/outside diameter of the air connections : 50/55mm
• - Filter Efficiency: > 98%
• - Total height : 31cm
• - Ships with 1 x mounting kit, 2 x 32mm , 2 x 35mm and 2 x 40mm adapters

[available_now] => in stock ! [available_later] => The DUST COMMANDER DLX ESD MKII is currently out of stock. Pre-orders are accepted. Shipments for this reference will resume on 22/03/2021. [link_rewrite] => cyclone-filter-dust-commander-dlx [meta_description] => Cyclonic filter allowing the separation of dust particles. Keeps your vacuum bag empty and offers a constant suction power. [meta_keywords] => [meta_title] => DUST COMMANDER DLX cyclone filter [name] => DUST COMMANDER DLX ESD MKII - High performance cyclone filter element/dust collector [id_image] => 9-118 [legend] => DUST COMMANDER DLX – Élément séparateur cyclone hautes performances [manufacturer_name] => Sulaco A.I.R Works [category_default] => Cyclonic Filters / Separators [new] => 0 [orderprice] => 38.250000 [allow_oosp] => 0 [category] => cyclonic-filters-separators [link] => https://www.dust-commander.com/gb/p/9-cyclone-filter-dust-commander-dlx-3760013430023.html [attribute_price] => 0 [price_tax_exc] => 38.25 [price_without_reduction] => 38.25 [reduction] => 0 [specific_prices] => [quantity_all_versions] => 27 [features] => Array ( [0] => Array ( [name] => Max. air flow [value] => 240m³/h [id_feature] => 10 ) [1] => Array ( [name] => Manufacturing material [value] => PA30GF electrically conductive (less than 1E6 ohms / square) [id_feature] => 5 ) [2] => Array ( [name] => Internal / external diameter of the inlet / outlet ducts [value] => 50/55mm [id_feature] => 8 ) [3] => Array ( [name] => Height [value] => 315mm [id_feature] => 1 ) [4] => Array ( [name] => Width [value] => 152mm [id_feature] => 2 ) [5] => Array ( [name] => Depth [value] => 178mm [id_feature] => 3 ) [6] => Array ( [name] => Weight [value] => 390 grams [id_feature] => 4 ) [7] => Array ( [name] => Color [value] => black [id_feature] => 7 ) ) [attachments] => Array ( ) [virtual] => 0 [pack] => 0 [packItems] => Array ( ) [nopackprice] => 0 [customization_required] => [rate] => 0 [tax_name] => [color_list] => [ptsimages] => Array ( [0] => Array ( [cover] => 1 [id_image] => 118 [legend] => DUST COMMANDER DLX – Élément séparateur cyclone hautes performances [position] => 1 ) [1] => Array ( [cover] => [id_image] => 122 [legend] => DUST COMMANDER DLX – Élément séparateur cyclone hautes performances [position] => 2 ) [2] => Array ( [cover] => [id_image] => 133 [legend] => DUST COMMANDER DLX – Élément séparateur cyclone hautes performances [position] => 3 ) [3] => Array ( [cover] => [id_image] => 115 [legend] => DUST COMMANDER DLX – Élément séparateur cyclone hautes performances [position] => 4 ) [4] => Array ( [cover] => [id_image] => 116 [legend] => DUST COMMANDER DLX – Élément séparateur cyclone hautes performances [position] => 5 ) [5] => Array ( [cover] => [id_image] => 117 [legend] => DUST COMMANDER DLX – Élément séparateur cyclone hautes performances [position] => 6 ) [6] => Array ( [cover] => [id_image] => 143 [legend] => DUST COMMANDER DLX – Élément séparateur cyclone hautes performances [position] => 7 ) ) [swapimage] => Array ( [cover] => [id_image] => 122 [legend] => DUST COMMANDER DLX – Élément séparateur cyclone hautes performances [position] => 2 ) ) 1

Array ( [id_product] => 15 [id_supplier] => 0 [id_manufacturer] => 2 [id_category_default] => 12 [id_shop_default] => 1 [id_tax_rules_group] => 10 [on_sale] => 0 [online_only] => 1 [ean13] => 3760013430436 [upc] => 84219990 [ecotax] => 0.000000 [quantity] => 5 [minimal_quantity] => 1 [price] => 299.17 [wholesale_price] => 0.000000 [unity] => [unit_price_ratio] => 0.000000 [additional_shipping_cost] => 0.00 [reference] => DUST-XL+ [supplier_reference] => [location] => [width] => 0.000000 [height] => 0.000000 [depth] => 0.000000 [weight] => 13.300000 [out_of_stock] => 1 [quantity_discount] => 0 [customizable] => 0 [uploadable_files] => 0 [text_fields] => 0 [active] => 1 [redirect_type] => 404 [id_product_redirected] => 0 [available_for_order] => 1 [available_date] => 2019-12-10 [condition] => new [show_price] => 1 [indexed] => 1 [visibility] => both [cache_is_pack] => 0 [cache_has_attachments] => 0 [is_virtual] => 0 [cache_default_attribute] => 0 [date_add] => 2019-09-22 13:43:53 [date_upd] => 2025-05-09 10:33:15 [advanced_stock_management] => 0 [pack_stock_type] => 3 [free_delivery] => 1 [id_shop] => 1 [id_product_attribute] => 0 [product_attribute_minimal_quantity] => [description] =>

• Large cyclonic filter for 1 to 3 HP dust collectors
• 125 mm inputs/outputs - optional 100mm adapters (ref MXL-ADA)
• Made from cold rolled carbon steel - mat/satin paint finish - black color
• Supplied with fixing screws and cutting guide

Package contents :

1 x DUST COMMANDER XL+ FILTER
1 x ASSEMBLY KIT

The DUST COMMANDER XL+ Mounting Kit includes :

6 x x ISO 7380F M5x12 stainless steel A2 hex button head socket screw with flange
6 x DIN 9021 M5 (5.3) stainless steel A2 washers
6 x DIN 934 M5 stainless steel A2 nuts
1 x silicone gasket
1 x self ashesive cutting template

DUST COMMANDER XL+ - datasheet

[description_short] =>

DUST COMMANDER XL+ - Large format cyclonic steel filter for use with HVLP dust collectors.

[available_now] => in stock ! [available_later] => [link_rewrite] => dust-commander-x-plusl-large-format-steel-cyclone-filter-element-dust-collector [meta_description] => Large format cyclonic steel filter for use with HVLP dust collectors. [meta_keywords] => [meta_title] => DUST COMMANDER XL + large format cyclone filter steel [name] => DUST COMMANDER XL+ - Cyclone filter element / Dust collector [id_image] => 15-75 [legend] => DUST COMMANDER CLC - Cyclone filter element / Dust collector [manufacturer_name] => Sulaco A.I.R Works [category_default] => Cyclonic Filters / Separators [new] => 0 [orderprice] => 299.166667 [allow_oosp] => 1 [category] => cyclonic-filters-separators [link] => https://www.dust-commander.com/gb/p/15-dust-commander-x-plusl-large-format-steel-cyclone-filter-element-dust-collector-3760013430436.html [attribute_price] => 0 [price_tax_exc] => 299.166667 [price_without_reduction] => 299.166667 [reduction] => 0 [specific_prices] => [quantity_all_versions] => 5 [features] => Array ( [0] => Array ( [name] => Max. air flow [value] => 4000 m3/h [id_feature] => 10 ) [1] => Array ( [name] => Manufacturing material [value] => cold rolled carbon steel - mat/satin paint finish - black color [id_feature] => 5 ) [2] => Array ( [name] => Height [value] => 84 cm [id_feature] => 1 ) [3] => Array ( [name] => Width [value] => 47.2 cm [id_feature] => 2 ) [4] => Array ( [name] => Depth [value] => 40 cm [id_feature] => 3 ) [5] => Array ( [name] => Weight [value] => 9.7 kg [id_feature] => 4 ) [6] => Array ( [name] => Color [value] => black [id_feature] => 7 ) ) [attachments] => Array ( ) [virtual] => 0 [pack] => 0 [packItems] => Array ( ) [nopackprice] => 0 [customization_required] => [rate] => 0 [tax_name] => [color_list] => [ptsimages] => Array ( [0] => Array ( [cover] => 1 [id_image] => 75 [legend] => DUST COMMANDER CLC - Cyclone filter element / Dust collector [position] => 1 ) [1] => Array ( [cover] => [id_image] => 128 [legend] => DUST COMMANDER CLC - Cyclone filter element / Dust collector [position] => 2 ) [2] => Array ( [cover] => [id_image] => 138 [legend] => DUST COMMANDER CLC - Cyclone filter element / Dust collector [position] => 3 ) ) [swapimage] => Array ( [cover] => [id_image] => 128 [legend] => DUST COMMANDER CLC - Cyclone filter element / Dust collector [position] => 2 ) ) 1
